PG2.54-0.9-66-SN Lead Frame for 1 mm Thick PCB, Horizontal Mount
Turn custom PCBs or adapter boards into horizontal DIP or SIP IC modules with the PG2.54-0.9-66-SN lead frame. Crafted in Japan through precision metal processing, this component features a standard 2.54 mm pitch designed for 1.0 mm thick circuit boards.
Each pin incorporates an individual spring clip mechanism to grip your board securely. This offset model positions the pins roughly 1 mm inside the edge of the mounted board, keeping horizontal installations tidy and structurally sound.
This item is brand new and unused, making it a reliable choice for your next custom electronics project.
Japanese-made precision metal lead frame for circuit boards. Features a 2.54 mm pitch and supports 1.0 mm-thick boards.
Allows conversion boards and homemade circuit boards to be easily configured as DIP/SIP horizontal-mount ICs. Each pin has a precision spring clip for secure board retention, with pins offset inward by approximately 1 mm from the held board.
