NAC SPLITFIRE JAMMA Video/Audio Splitter Controller Board New
The NAC SPLITFIRE is a brand new JAMMA video and audio splitter manufactured in 2025, designed to sit directly between your arcade PCB and cabinet or control box. It splits the audio and video signals right at the source with zero added latency, pulling the signal straight from the board rather than routing it through the control box. That means a cleaner, more stable image split, making it a great choice for building head to head versus cabinets or creating a parallel feed for capture devices without touching your main video stability.
Arcade setups can get messy when you're trying to send signal to modern displays or capture cards. The NAC SPLITFIRE simplifies that with a clean D-sub 15-pin video output: just plug in a standard VGA cable and connect straight into popular upscalers like the OSSC, VC9900, or GBS-8220.
This board uses a Hirose connector (CR7E-56DA-3.96E) and includes one Hirose G-Pin to help prevent reverse insertion and protect your hardware. It also features built in volume knobs for both video and audio, giving you precise control over the output for your specific setup.
NAC SPLITFIRE is a 2025-model JAMMA video and audio splitter for branching signals between a JAMMA PCB and an arcade cabinet or control box. It features a 15-pin D-sub video output compatible with standard VGA cables for connection to upscalers such as the GBS-8220, VC9900, and OSSC.
Suitable for building versus cabinets or splitting a capture input alongside a zero-latency setup. Includes a Hirose CR7E-56DA-3.96E connector and one Hirose G-Pin reverse-insertion prevention pin. Features separate video and audio volume controls. By drawing the signal directly from the PCB output, it can provide more stable image splitting than routing through a control box video output, depending on the capture equipment and configuration.
