The Phasemation PP-200 MC cartridge captures the realism etched into every groove, drawing out even the artist's raw emotion. Designed as a new standard model, it brings the soundstage and spatial presence of flagship designs like the PP-2000 into a more accessible package. Phasemation is celebrated in the Japanese high-end audio scene for building analog components that deliver fresh, detailed highs and rich low frequencies straight from the source recording.
This moving coil cartridge features a newly shaped body engineered to control unwanted vibration, with a precision-machined aluminum housing paired with a duralumin base. Inside, a powerful neodymium magnet and pure iron magnetic circuit work alongside 6N oxygen-free copper coils to produce an output voltage of 0.3mV or higher.
The improved vibration system relies on a solid 0.26mm boron cantilever and a line-contact diamond stylus tip with a 0.03 by 0.003mm curvature, both proven on the flagship PP-2000, for enhanced tracking across a wide 10Hz to 30kHz frequency range.
Weighing 10.5 grams, the cartridge operates at an impedance of 4 ohms with a recommended tracking force of 1.7 to 2.0 grams. Technical specifications include a compliance of 8.5μm/mN, channel separation of 25dB or higher, and channel balance within 1dB.
This item is brand new, ready to bring direct, pure sound quality straight from Japan to your turntable.
Phasemation PP-200 moving coil (MC) cartridge, a new standard model incorporating technologies and materials proven in higher-end models, including the PP-2000. It features a neodymium magnet magnetic circuit, a diamond line-contact stylus, solid boron cantilever, and 6N oxygen-free copper voice coil. The newly shaped machined aluminum body is designed to control unwanted vibration.
Specifications: moving coil generator system; 4 ohm impedance; recommended tracking force 1.7 to 2.0 g; output voltage 0.3 mV or higher (1 kHz, 50 mm/s horizontal); compliance 8.5 μm/mN (8.5 × 10⁻⁶ cm/dyne); frequency response 10 Hz to 30 kHz; channel separation 25 dB or higher (1 kHz); channel balance within 1 dB (1 kHz). The cantilever is solid boron, 0.26 mm diameter; magnet is neodymium; magnetic circuit material is pure iron. The base is machined duralumin, and the body is machined aluminum. Weight: 10.5 g. Stylus: diamond line-contact, 0.03 × 0.003 mm radius.
